• Patent design: the pilots of double control valve are on same side; Wiring and piping are on same side. • .5/2 ways,5/3 ways,5/4 ways(2pcs 3/2 ways ) can be selected • 0.8W per coil.

• Integrated valve terminal , integrated wiring ;Adopt25 pins D-sub connector. • Centralized air inlet and exhaust, available for top ported ,side ported and bottom ported，compact structure. • Patent design: the pilots of double control valve are on same side; Wiring and piping are on same side. • .5/2 ways,5/3 ways,5/4 ways(2pcs 3/2 ways ) can be integrated on same valve terminal. • 0.8W per coil.

• Direct acting , sensitive action; • Zero pressure starting , suitable for vacuum application; • Universal for N.C .& N.O. type, suitable for 8 kinds applications; • Coaxial shut - off design , balanced spool without back pressure , no influence from working medium pressure , high anti -- dirty and excellent sealing; • Multiple mounting types , manual button equipped for convenient debugging.

• Integrated valve manifold,integrated wiring, adopt 15-pin D-Sub connector.COM pin is universalfor both positive pole and negative pole. • 5/2 ways single control, 5/2 wavs double control, 5/3 wavs can be integrated on same valve manifold. • Integrated valve manifold own double control core technical patent initiative design. • Each connector with LED more intuitive. • With DIN coils, more convenient in assembling & maintenance,low-power type is optional, achieve energy saving 80%. • Newly designed sub-base, installation size same as RV manifold, DIN guide rail assembly on optional.

• 3/2 Direct Acting, reversing fast, zero-pressure/low vacuum start. • Double-row valve integrated, greatly save installation space. • 37 Pins D-sub connector save assembly time, COM terminal non-polar. • Single valve DIN coil, plate mounting with seals, easily maintenance.

• Centralized air inlet and exhaust available for top ported. • The connector upwards for quick and easy installation of wiring. • 5/2 ways, 5/3 ways, 5/4 ways(2pcs 3/2ways)can be integrated on same valve terminal. • 0.8W per coil.

*Compatible Protocols: l/0-Link, general-purpose 5-wire unshielded cables are used for connection //O-Link master and exchange data with PLC. *16 outputs Max.16pcs single control/8pcs double control/16pcs stations. *Support hot swap, data is stored in the /O-Link master, no need to reconfigure parameters to replace the valve terminal, the newly replaced is automatically identified and start to work at once, reduce equipment downtime, reduce maintenance costs, and improve production efficiency. *Diagnostic functions: system diagnosis, communication error, short circuit protection. * Independent of fieldbus, possess strong industrial network compatibility, supply popular fieldbus and industry Ethernet; Simple installation and configuration easy to operate. *Communication is completely digitally transmitted, reduce the accuracy loss of analog-to-digital conversion, possess strong anti-interference ability.

• Compatible Protocols:PROFINET、EtherCAT、EtherNet/IP、DeviceNet and CC-Link. • 32 output and 48 output optional. • Equipped with two M12 BUS Interface, realize daisy-chain wiring communication, branch connector ls not necessary. • system diagnosis,communication error,working life count,short circuit protection,open circuit inspection, opposite connection protection , undervoltage and overvoltage diagnosis. • Safe output can be set a any point in module parameter interface.For example, when the bus connection is interrupted, the valve could keep the last condition, or be forced to close or open. • The shielded cable has strong anti-interference ability and the communication is stable and reliable. IO-Link: • Compatible Protocols:l/O-Link,general-purpose 5-wire unshielded cables are used for connection l/O-Link master and exchange data with PLC. • Support hot swap,data is stored in the l/0-LINK master,no need to reconfigure parameters to replace the valve island,The newly replaced is automatically identified and start to work at once,reduce equipment downtime, reduce maintenance costs, and improve production efficiency. • Diagnostic functions:system diagnosis,communication error,short circuit protection. • Independent of fieldbus,possess strong industrial network compatibility,supply popular fieldbus and industry ethernet. • Communication is completely digitally transmitted,reduce the accuracy loss of analog-to-digital conversion,possess strong anti-interference ability.Maximum transmission distance is 20 meters.
